상세스펙
Specifications
| Type | Integrated tube amplifier |
| Tubes | 2 x 845 selected, 4 x ECC82/12AU7 selected |
| Class | Pure class A |
| Output stage topology | Single-ended |
| Maximum power | 23W |
| Bandwidth | 20Hz-50kHz, +0dB; -1dB @ 12W |
| Feedback level | 14 dB |
| Output impedance | 6 Ω |
| Input impedance | 47 kΩ/100pF |
| Inputs | 4 line level |
| Outputs | 1 tape, 1 subwoofer |
| Power consumption | 300VA |
| Sizes | Without packaging : 37 cm x 26cm x 57 cm (LxHxD) |
| Weight | 30,5 kg |
| Mains fuses | 5x20mm – 6.3 AT 100V-120V 5x20mm – 3.15 AT 220V-240V |
