Specifications
| Valve complement | 5 x ECC83/12AX7 |
| Amplification class | pure class A |
| Negative feedback | zero |
| Gain | 54dB approx. |
| RIAA | passive 0.1dB tolerance |
| Input impedance | 47kΩ, 100Ω, 47Ω, 20Ω 100pF, 200pF, 320pF, 420pF any custom value |
| THD | <0.1% @ 1kHz, 5mV input |
| SNR | <-80dB @ 5mV input |
| Noise | <0.5uV eq. input voltage, A-weighted |
| Max Out Voltage | 40Vrms @ 5% THD |
| Dimensions | 14.7in x 2.3in x 9.7in |
| Net weight | 8lbs |
