Specifications
| Power output | 85W RMS on 8 both channels driven |
| Frequency response | -0.1dB @ 10Hz / -0.5dB @ 100kHz |
| Input impedance | 47k // 47pF |
| Sensitivity | 260mV RMS |
| Input stage | Pure Class A. Parallel ECC83/12AX7 (2x) |
| Output stage | Dynamic Class A POWER MOSFET in complementary pair |
| Inputs | 5 line RCA (1 phono optional) |
| Line outputs | 1 tape, 1 sub (volume controlled) |
| Output connectors | 4 + 4 bi-wiring |
| Feedback factor | 10dB |
| THD | < 0.15% @ 1kHz, 10W |
| Power consumption | 380W max |
| Dimensions | 17.1in x 3.5in x 17in |
| Weight | 31lb |
| PHONO STAGE (optional) | |
| Input impedance | 47k // 220pF MM 100 // 440pF MC |
| Gain | 40dB MM, 50dB MC |
| Gain setting | +0dB / +10dB |
| Max input voltage | 120mV @ 1kHz |
| RIAA | active at low frequency, passive at high frequency |
| THD | 0.09% @ 5mV, 1kHz, MM |
