Specifications
| Output power | 150+150 W RMS at 88Ω 220+220 W RMS at 4Ω |
| Frequency response | -1dB @ 12Hz & 45kHz, -3 dB @ 6Hz & 80 kHz |
| Input impedance | 24kΩ // 100pF |
| Input sensitivity | 860mV RMS |
| Input stage | Pure A class, double triode totem pole ECC83 |
| Driver stage | Pure A class, double triode totem pole 6H30 |
| Output stage | Class AB thermostable, complementary Hexfet (4 pairs for channel) |
| Input | 6 line (3 unbalanced, 2 balanced, 1 “bypass” unbalanced) |
| Line Outputs | 1 tape, 1 sub (volume controlled) |
| Output connectors | 4 + 4 bi-wiring |
| Global Feedback factor | 0 dB |
| Local Feedback factor | 16 dB |
| THD | < 0.15% @ 1kHz, 1 W < 0.25% @ 1kHz, 10 W < 0.35% @ 1kHz, 100 W < 0.9% da 20 a 20000 Hz, 150 W |
| Output resistance | <0.4Ω, resistive on all audio frequencies |
| Power Consumption | 550 W (at max power on 8 ohm) |
| Dimensions | 43.5 cm x 18 cm x 44 cm |
| Net weight | 25 kg |
