상세스펙
Digital Input
| 1 x USB | Standard : USB 2.0 Audio Class frequencies : 44.1, 48, 88.2, 96, 176.4, 192, 352.8, 384, DSD64, DSD128, DSD256 Ready Resolution : 16 to 32 bits |
| 1x Toslink™ | Sampling frequencies : 44.1, 48, 88.2, 96 (176.4 and DSD64 DoP with high efficiency transmitters) Resolution : 16 to 24 bits |
| 1 x Bluetooth™ Receiver | Standard : BT 3.0 Profiles : A2DP, SSP (HID supported with Android smartphones through SPP) Sampling frequencies : 44.1kHz, 48kHz Resolution : 16 bits |
Digital Output
| 1x S/PDIF | Output voltage: 0.5Vpp on 75 Ohms |
Transport
| Transport | 8829CD-KHM DVD-Loader , Only audio CD |
Display
| Display | 128 X 64 White OLED graphic display |
Digital to Audio stage
| DAC | ESS Sabre ES9018K2M with jitter eliminator SNR : 125dB (0dBFS, 1kHz, 192kHz, “A” weighted) THD+N : 0.0003% (0dBFS, 1kHZ, 20Hz-20kHZ) Timing : low phase noise, high precision crystal oscillators |
| IV converter | NE5532AD high-performance, very low noise, use high-quality components like wima capacitor and wishay resistor |
Output Audio stage
| channel | 2 |
| Output stage | Duble Triode, pure class A |
| Valve complement | 1 x 12AU7/ECC82 |
| Output audio connectors | 1 x RCA stereo |
| Optional buffer | NE5532AD output buffer that bypass tube stage, can be activated by remote control |
General Specification
| Remote control | 1 x Infrared in wood and metal |
| Disc Formats | CD Audio |
| Power consumption | 100W max |
| Dimension | 45cm x 38cm x 13cm |
| Net weight | 10Kg |
