상세스펙
General
| General Description | 2-way atmos speaker |
| Enclosure Type | closed-box system |
| Transducer Complement | 2-way |
ABR
| Bass Driver | 4" (100mm) advanced PP Cone |
Midrange Driver
| Treble Driver | 1" (25mm) Textile Dome |
Full-range Driver
| AV Shield | No |
| Sensitivity (2.83V @ 1m) | 82dB |
| Recommended Amplifier Power | 20-100W |
Peak Power Handling
| Peak SPL | 95dB |
| Nominal Impedance | 8Ω Compatible |
| Minimum Impedance | 4.3Ω |
| Frequency Response (+/-3dB) | 110Hz - 20kHz |
| Bass Extension (-6dB) | 90Hz |
| Crossover Frequency | 3kHz |
| Cabinet Volume (in litres) | 2.7L |
| Dimensions ( H x W x D ) | 145 x 180 x 310mm |
| Net Weight | 3.2kg/pcs |
