Specifications
| General description | 3-way vented-box / Standmount |
| Design philosophy and core technology | |
| Enclosure type | Bass Reflex |
| Transducer complement | 3-way |
| ABR | |
| Bass driver | 8"(200mm) Black Woven Kevlar Cone |
| Midrange driver | 5"(135mm) Black Woven Kevlar Cone |
| Treble driver | 1"(25mm) Soft Dome |
| Sensitivity (2.83V @ 1m) | 90dB |
| Recommended amplifier power | 25 - 200W |
| Peak SPL | 110dB |
| Nominal impedance | 6Ω (Compatible 8Ω ) |
| Minimum impedance | 3.9Ω |
| Frequency response(+/-3dB) | 39Hz - 20kHz |
| Bass extension(-6dB) | 32Hz |
| Crossover frequency | 550Hz & 2.5kHz |
| Cabinet volume (in litres) | 6.6L, 33.4L |
| Dimensions (mm) | nan |
| Height (on plinth) | 605mm |
| Width | 300mm |
| Depth (with terminals) | (330+20)mm |
| Carton size | 465 x 435 x 740mm |
| Net weight | 19.8kg / pcs |
| Gross weight | 22kg / ctn |
