Specifications
| General description | 2-way vented-box/standmount |
| Enclosure type | bass reflex |
| Transducer complement | 2-way |
| Bass driver | 6.5"(165mm) Black Woven Kevlar Cone |
| Treble driver | 1"(25mm) Soft Dome |
| Sensitivity(2.oV @ 1m) | 88dB |
| Recommended amplifer power | 20 - 120W |
| Peak SPL | 95dB |
| Nominalimpedance | 4Ω |
| Minimum impedance | 3.8Ω |
| Frequency response(+/-3dB) | 45Hz ~ 20kHz |
| Bass extension(-6dB) | 40Hz |
| Crossover frequency | 3.1kHz |
| Cabinet Volume (in litres) | 13.5L |
| Dimensions(mm) | |
| Height (on plinth) | 340mm |
| Width | 240mm |
| Depth(with terminals) | (275+12)mm |
| Carton size | 620 x 380 x 445mm |
| Net weight | 9.0kg/pcs |
| Gross weight | 21.0kg/ctn |
