General
| General description | Centre Speaker |
| Enclosure type | Bass Reflex |
| Transducer complement | 2-way |
| Bass driver | 125mm Xoven Kevlar Cone x2 |
Midrange driver
| Treble driver | 25mm Soft Dome |
| AV shield | Yes |
| Sensitivity(2.83V @ 1m) | 89dB |
| Recommended amplifer power | 25 - 100W |
| Peak SPL | 95dB |
| Nominal impedance | 8Ω Compatible |
| Minimum impedance | 4.2Ω |
| Frequency response(+/-3dB) | 70Hz - 20kHz |
| Bass extension (-6dB) | 65Hz |
| Crossover frequency | 2.4kHz |
| Cabinet Volume (in litres) | 8.2L |
Dimensions(mm)
| Height (on plinth) | 172mm |
| Width | 415mm |
| Depth(with grille&terminal) | (192 + 10)mm |
| Carton size | 495 x 280 x 260mm |
| Net weight | 6.8kg each |
| Gross weight | 8kg/ctn |
