Specifications
| System | Reflex, floor-standing with rear firing radiation system (dipole). |
| Front Driver | 1 x 8” long-throw woofers, 1 x 7” midrange with polypropylene recooked cone and phase plug. 1 x 1” Scan-speak 9700 tweeter without ferrofluid and double decompression chamber" |
| Rear Driver | 2 x 1” tweeters in “natural dipole” assembly |
| Number of ways | 3 ways + rear dipole |
| Fq Response | 30 -25000 Hz |
| Cross-over | 12 dB/ott. For woofers 12 dB/ott for midrange 12 dB/ott for the front tweeter 12 dB/ott for the rear tweeters frequencies 200 e 2000 Hz ( aprox ) |
| Max Power | 240 Watt (without clipping) |
| Sensitivity | 90 dB/2.83 Volt/1 meter |
| Impedance | 4 ohm (Z min >3.2 ohm) |
| Room Position | At least 10 cm from the rear wall |
| Size and Weight | 116 x 37 x 53,5 cm (HxLxP) 65 Kg each including metal base |
| Finishes | Lacquered Mahogany / Lacquered Walnut |
