Specifications
| System | Reflex, foorstanding with rear fireing radiation system (dipole). Finish in wood and leather. Bi-wiring. Support for spikes or wheels. |
| Front firing loudspeakers | 2 x 8” long-throw woofers, 1 x 7” midrange with polypropylene recooked cone and phase plug. 1 x 1” Scanspeak 9700 tweeter without ferrofluid and double decompression chamber |
| Rear fireing loudspeakers | 2 x1” tweeters in “natural dipole” assembly |
| Number of ways | 3 ways + rear dipole |
| Frequency Response | 32 -25000 Hz |
| Cross-over | On 2 PCB 12 dB/ott. For woofers 12 dB/ott for midrange 18 dB/ott for the front tweeter 12 dB/ott for the reas tweeters Cross-over frequencies 200 e 2000 Hz (aprox.) |
| Max Power (long period) | 240 Watt (without clipping) for musical programs with crest factor about 3 |
| Max Power (Short period) | 500 Watt (without clipping) for musical programs with crest factor more than 5 |
| Amplifier | Starting from 10 Watt RMS |
| Sensitivity | 89 dB/2.83 Volt/1 meter |
| Nominal impedance | 4 ohm (Zmin >3.2 ohm) |
| Position in the room | At least 20 cm from the rear wall |
| Size | 130 x 31 x 55 cm (HxLxP) |
| Weight | 75 Kg each |
| Finishing | Walnut, Mahogay |
