상세스펙
Specification
| Frequency response 1 | 29 Hz - 27 kHz (-6 dB) |
| Recommended amplifier power | 20 - 250 W |
| Power handling (IEC) | 125 W continuous, 500 W peak |
| Nominal dispersion | 90 degrees conical |
| Sensitivity 2 | 93 dB (1 W @ 1 m) |
| Impedance | 8 Ω |
| Minimum Impedance | 5 Ω |
| Maximum SPL 2 | 114 dB continuous, 120 dB peak |
| Low frequency dual concentric | 250 mm (10") with paper pulp cone with twin roll impregnated fabric surround, 52 mm (2") round wire voice coil |
| High frequency dual concentric | 52 mm (2") aluminium/magnesium alloy dome with round wire voice coil and mylar surround |
