상세스펙
Line in
| Gain Line 1-4 | 5-15dB; max input 4.5V RMS |
| Gain Line 5 | 1-11dB; max input 6.5V RMS |
| Input impedance | 10K Ω |
Pre out
| Pre out | 1 single ended – RCA |
| Max output | 7.5V RMS |
| Distortion, line stage | <0.005% (THD at 1kHz, 1V input) |
| Output impedance | 50 Ω |
Amplifier Section
| Volume Control | 76 dB – 1dB steps |
Aavik Noise Reduction
| Active Tesla coils | 314 |
| Active Square Tesla coils | 663 |
| Dither circuitry | 36 |
| Active zirconium anti aerial resonance Tesla coils | 2 |
Power consumption
| Standby | 1 W |
| Idle | 12 W |
General
| Dimensions (L×W×H) | 580 x 510 x 155 mm |
| Weight | 35 kg |
