상세스펙
Specifications
| Line Input | Maximum input 4.5V RMS Maximum input 6.5V RMS (Line 2) Input impedance 10kΩ |
| Digital Input | USB UAC 2 : PCM 32-bit, 44–384 kHz; MQA; DSD64; DSD128 BNC S/P-DIF : PCM 24-bit 44-192kHz and MQA Toslink Optical : PCM 24-bit, 44–192 kHz; MQA |
| Preamp Output | 1 pair of RCA outputs Max Output : 7.5Vrms Volume control : 76 steps (1 dB each) |
| DISTORTION LINE | STAGE : 0.005% (THD at 1kHz, 1V input) |
| OUTPUT IMPEDANCE | 50 Ω |
| VOLUMECONTROL | 76 1dB steps |
| SPEAKER OUTPUT | 2 x 300W 8 Ω 2 x 600W 4 Ω |
| DISTORTION (THD+N) | 0.0028% (1W, 1kHz, 8 Ω) |
| IMD | 0.0008% (10W, 8 Ω) |
| TIM | 0.002% (10W, 8 Ω) |
| STREAMING | AV 1.0 DLNA 1.5 |
| AAVIK NOISE REDUCTION | |
| Active Tesla Coils | 108 |
| Active Square Tesla Coils | 259 |
| Dither circuitry | 10 |
| Anti Areal Resonance Coils | 7 |
| POWER CONSUMPTIO | |
| Standby | 1W 30W |
| INPUT VOLTAGE | 100-240 V |
| MAX CURRENT | 10 A |
| DIMENSIONS (WxDxH) | 440 x 430 x 116mm |
| WEIGHT | 22.8kg |
