상세스펙
Line in
| Gain Line 1-4 | 5-15dB; max input 4.5V RMS |
| Gain Line 5 | 1-11dB; max input 6.5V RMS |
| Input impedance | 10K Ω |
Pre out
| Pre out | 1 single ended – RCA |
| Max output | 7.5V RMS |
| Distortion, line stage | <0.005% (THD at 1kHz, 1V input) |
| Output impedance | 50 Ω |
Amplifier Section
| Volume Control | 76 dB – 1dB steps |
| Output | 2 x 200W 8 Ω 2 x 400W 4 Ω |
| Distortion (THD) | <0.007% (10W, 1 kHz, 8 Ω) |
Aavik Noise Reduction
| Active Tesla Coils | 132 |
| Active Square Tesla Coils | 311 |
| Dither circuitry | 18 |
| Active zirconium anti aerial resonance Tesla coils | 20 |
| Active zirconium cable anti aerial resonance Tesla coils | 4 |
Power consumption
| Standby | <1W |
| Idle | <150W |
General
| Dimensions (L x W x H) | 580 x 510 x 155 mm |
| Weight | 36 kg |
