상세스펙
MC Inputs
| Floating RCA (1 set) | |
| Max input | 5mVrms |
| Gain | 58dB or 64dB @ 1 kHz |
| Input load resistance | 50 Ω to 10k Ω (Adjustable) |
Frequency Response (MC)
| 58dB | +0.1/-0.4dB (20Hz-20kHz) |
| 64dB | +0.1/-1.1dB (20Hz-20kHz) |
Optical input
| RCA (1 set) | |
| Max input | 500mVrms |
| Gain | 26dB |
Frequency Response
| Frequency Response (Optical) | +0.1/-0.3dB (20Hz-20kHz) |
Output
| 1 pair of RCA outputs | |
| Distortion | <0.05% (THD at 1kHz, nominal input) |
| Output impedance | 70 Ω |
Aavik noise reduction
| Active Tesla Coils | 36 |
| Active Square Tesla Coils | 72 |
| Dither circuitry | 3 |
Power consumption
| Standby | <1W |
| On | <15W |
General
| Dimensions | 440 x 430 x 116mm |
| Weight | 21kg |
| Mains voltage and current | 100-240V AC – 50-60 Hz max 3, 15A |
| Enclosure classification | IP10 |
