상세스펙
MC Inputs
| Floating RCA (1 set) | |
| Max input | 5 mV RMS |
| Gain | 58 dB or 64 dB @ 1 kHz |
| Input load Resistance | 50 Ω – 10 k Ω (Adjustable) |
Frequency Response (MC)
| 58 dB | +0.1/-0.4 dB (20 Hz-20 kHz) |
| 64 dB | +0.1/-1.1 dB (20 Hz-20 kHz) |
Optical Input
| RCA (1 set) | |
| Max input | 500 mV RMS |
| Gain | 26 dB |
Frequency Response (Optical)
| Frequency Response (Optical) | +0.1/-0.3 dB (20 Hz-20 kHz) |
Output
| 1 pair of RCA outputs | |
| Distortion | < 0.05 % THD at 1 kHz (nominal input) |
| Output impedance | 70 Ω |
Aavik Noise Reduction
| Active Tesla Coils | 72 |
| Active Square Tesla Coils | 144 |
| Dither circuitry | 6 |
Power Consumption
| Standby | < 1 W |
| On | < 15 W |
General
| Dimensions (W × D × H) | 440 × 430 × 116 mm |
| Weight | 21 kg |
| Mains Voltage and Current | 100-240 V AC – 50-60 Hz max 3, 15 A |
| Enclosure Classification | IP10 |
