상세스펙
MC Inputs
| Floating RCA (1 set) | |
| Max input | 5 mV RMS |
| Gain | 58 dB or 64 dB @ 1 kHz |
| Input Load Resistance | 50 Ω – 10 kΩ (Adjustable) |
Frequency Response (MC)
| 58 dB | +0.1 / −0.4 dB (20 Hz–20 kHz) |
| 64 dB | +0.1 / −1.7 dB (20 Hz–20 kHz) |
Optical Input
| RCA (1 set) | |
| Max input | 500 mV RMS |
| Gain | 26 dB |
Frequency Response (Optical)
| Frequency Response (Optical) | +0.1 / −0.3 dB (20 Hz–20 kHz) |
Output
| 1 pair of RCA outputs | |
| Distortion | < 0.05 % THD at 1 kHz (nominal input) |
| Output impedance | 70 Ω |
Aavik Noise Reduction
| Active Tesla Coils | 108 |
| Active Square Tesla Coils | 216 |
| Dither circuitry | 9 |
Power Consumption
| Standby | < 1 W |
| On | < 40 W |
Dimensions/Weight
| Dimensions (W × D × H) | 440 × 430 × 116 mm |
| Weight | 21 kg |
