Specifications
| Type | Valve Power Amplifier |
| Valves | V1L/R : ECC83/12AX7 V2L/R, V3L/R, V4L/R : KT77 |
| Operating Mode | Pure Class A |
| Output Stage | Triple parallel single-ended |
| Bias | Fixed, partially user-adjustable |
| Inputs | 4 Analog inputs 3 Digital inputs (Usb, Optical, S/Pdif) |
| Output Power | 40W on 6Ω |
| Input Impedance | 47kΩ : Unbalanced |
| Outputs | Speaker outputs Sub Out line level, not filtered |
| Output Impedance | 6Ω |
| Power Consumption | 265VA approximately |
| Dimensions | 35 x 49 x 22 cm (w x d x h) 14 x 19.3 x 8.7 inches (w x d x h) |
| Net Weight | 25kg (55lbs) |
| Main Fuse | 6.3AT slow blow (100V-120V) 3.15AT slow blow (220V-240V) |
| DAC | |
| Converter | Sabre ES9018K2M |
| USB | PCM up to 384kHz DSD native up to 256x DoP up to 128x |
| Tos-link | Up to 192kHz |
| S/PDIF | Up to 192kHz |
