상세스펙
Specifications
| Output stage | Push-pull, ultralinear, Class-AB |
| Output power | Approx. 45 watt per channel Pentode configuration Approx. 25 watt per channel Triode configuration |
| Output impedance | 6 Ohm |
| Input impedance | 47kohm / 50 pF |
| Negative feedback | 5 dB or 1.8 dB |
| Valve complement | 2 x ECC83 (12AX7) 1 x ECC82 (12AU7) 4 x EL34 (6CA7) |
| Power consumption | 300 watt ( Max.) |
| Fuses | T6.3A from 100V to 130V T3.15A from 220V to 250V |
| Dimensions (mm.) | 30cm x 45cm x H. 20cm |
| Net weight | 20kg |
